PRODUCT DETAILS

ROLLING SHUTTER DOOR
Standard Width: 95mm
Max. length: 11.8m
Material: Galvanised steel 0.45mm thickness Epoxy paint
Foaming:PU foam
  • Rolling Shutter Door

    Steel rolling shutter doors are constructed with double-layered color-coated steel plates, filled with polyurethane foam in between, providing enhanced insulation and long-lasting durability.

    Steel rolling doors are typically used in workshops, warehouses, factories, or shops, and sometimes in residential garages.

    Xufeng Door offers a wide range of styles for rolling shutter doors. From traditional aesthetics to classic steel designs or sleek modern options, we provide all the design elements and features you need to turn your vision into reality.



    Why Choose XUFENG European Type Garage Door?




    • Experienced: Over 36 years of production experience manufacturer

    • Durability: Rolling doors are made of high-quality steel,making them highly durable and corrosion-resistant,capable of withstanding harsh weather conditions.

    • Customizable: Available in various sizes, colors, and finishes tomeet different needs and styles.

    • Easy Installation: Rolling doors can be installed in the middle,inside, or outside.

    • Insulation: Filled with eco-friendly polyurethane foam, they offerexcellent thermal insulation and help reduce energy loss.

    • Safety: Steel rolling doors include multiple safety features to keep you protected.

    • Low Maintenance: Designed for long-term use, they require minimal upkeep.

    • Versatility: Suitable for industrial, commercial, and residential applications.


    Product Details

    Product TypeRoller Shutter Door
    Applicable Door Size

    Max Width: 10000mm

    Max Height: 6000mm

    Head Room500-1000mm
    Side Room≥120mm
    Working Voltage380V
    Frequency50Hz
    Motor Power460-1350W
    Slat Width95mm
    ApplicationCommerical, Residential House, Warehouse
    Open StyleRoller
    IncludingShutter Slat, Aluminum Guide Track & Bottom, Shaft, End Cap
    Safety OptionalPhotocell, Air Bag Bottom
    MaterialGlavanised Steel, PU foam CFC free
    Steel Thickness0.45mm Thickness
    Panel Color

    Standard: RAL9002 Offwhite. Other Colors can be Customed

    Panel Weight12.4kg/m2
    Adaptive Temperature-40~50℃
    Wind Load Resistance650Pa
    Speed0.17m/s
    Surface TreatmentFinished


    Product Structure


    Rolling Shutter Slat


    Standard Width: 95mm


    Max.Length:11.8m


    Material: Galvanised steel 0.45mm thickness


    Epoxy paint


    Foaming: PU foam




    Steel Shutter Series for door


    95mm Salt



    Track



    Bottom Beam



    Windproof Roller Shutter Door Series

    The windproof rolling shutter door is made up of key components such as the curtain panel, wind-resistant wheels, windproof track, door-opening mechanism, and more. The inner layer of the curtain panel is filled with polyurethane foam, offering superior heat preservation, insulation, soundproofing, and aesthetics compared to standard curtain panels.

    Each end of the rolling shutter salt is equipped with wind-resistant wheels. As the door opens and closes, these wheels glide along the windproof track. When strong wind pressure occurs, the wind-resistant wheels pull the curtain panel securely in place, preventing derailment and enhancing wind resistance.

    This type of door is widely used in workshops, warehouses, and similar facilities.


    Windproof Rolling Shutter

    Patent No.: ZL201220167671.3

    In the event of wind load,the windproof wheel holds on to the windproof rail to prevent the shutter curtain from derailing and play a role of resistance to wind.


    Shutter Salts Wind-resistant Wheels

    Patent No.: ZL201220167671.3


    Windproof Rolling Door Salts

    Patent No.: ZL201220167671.3



    Windproof Rolling Shutter

    Patent No.: ZL201220167671.3



    Windproof Rolling Shutter Slats

    Patent No.: ZL201220167671.3


    Windproof Rail

    Aluminum alloy or profiled bar material is an option in terms of the users' demand.



    Track



    Track



    Bottom Beam



    Seals


    Rolling Support

    Patent No.:ZL201220168038.6

    Automatic adjustment mechanism of rolling door

    When opening or closing the rolling door, the rolling support makes automatic adjustment of the relative positions of the door body and the rail, hence reducing the resistance and extending the service life of the door.








    RFQ


    Q1:What is your MOQ?

    Re:No limit based on our standard color.Customized color need 10000m


    Q2:What is the delivery time?

    Re:About 15-30days, need check stocked raw material spec is enough or not.


    Q3:What is the Max. available size of the panels?

    Re:The max. length of panel can be 11.8m.


    Q4:What about your package?

    Re:Carton box for full container order, Polywood box for sample order


    Q5:What kind of payment terms would you accept?

    Re:Usually we accept T/T, L/C, Western Union, Credit Card etc. If you prefer other payment terms, please feel free to discuss with us.


    Q6:We want to be your agent of our area. How to apply for this?

    Re:Please send your idea and your profile to us. Let's cooperate.


    Q7:Can I get a sample to check your quality?

    Re:Sample panel is available.


    Q8:How can I know the price exactly?

    Re:Please give the exactly size and quantity of your required door. We can give you a detail quotation based on your requirements.


    Q9:Is it difficult to install your door?

    Re:Easy to install. We have manual book and installation video for your reference.We also provide support for training your staff in our factory or let our engineer go to your city provide techinical support.


    Q10:Do you produce other products? What about your export experience?

    Re:We produce sectional garage door, industrial door, roll shutter door, high speed door, hangar door etc.We had export since 2003 year, we have cooperated with Low'es, RONA etc.Had designed and produced for Maldives airport. Mongolia airport, Nepal airport, Romania airport etc.
