PRODUCT DETAILS

EUROPEAN TYPE GARAGE DOOR
Finger Protectional Type Panel
Standard Width: 480mm,500mm,530mm,550mm
Max. length: 11.8m
Thickness: 40+2mm
Density: 45±2kg/m3
Material: Galvanised steel Epoxy paint
Foaming: PU foam DOW

  • European Type Garage Door

    European type garage doors are made with double-layered color steel panels, filled with high-density polyurethane foam for insulation.

    The garage door panels are designed with finger protection, ensuring enhanced safety and lasting durability.

    Xufeng Door offers a wide range of styles for European type garage doors. From traditional aesthetics to classic steel designs or sleek modern options, we provide all the design elements and features you need to turn your vision into reality.


    Why Choose XUFENG European Type Garage Door?


    • Over 36 years of production experience manufacturer

    • Support full customization, including garage door panel size, color, design, thickness, width, safety features, materials, and more.

    • Made with eco-friendly, fluoride-free polyurethane foam

    • European-style garage doors provide excellent insulation, effectively preventing heat transfer and reducing energy loss.

    • Steel garage doors are strong, durable, and built to withstand wind, rain, and impact, ensuring long-term reliability.

    • European-style garage doors require little maintenance, with cleaning and upkeep being simple and hassle-free.



    Product Details

    Product TypeInsulation Sectional Garage Door
    ApplicationResidential House, Villa
    Open StyleOverhead Lift
    Including2" Galvanised Hardware, 3" Galvanised Hardware, Torsion, Tension, Rear Spring Type
    Safety OptionalSpring Broken Device, Cable Broken Device, Photocell, Warning Light
    MaterialGlavanised Steel, PU Foam (DOW) CFC Free, EPDM Rubber Seal, PE Protective Film
    Steel Thickness0.326mm, 0.45mm thickness
    Panel Color

    Standard: RAL9016 White, Optional: RAL7016 Grey, RAL9017 Black, RAL8017 Brown,

     RAL9006 Silver, Wooden Color etc. Other Colors can be Customed

    Panel DesignFinger Protection
    Panel Weight8.3kg/m2-10.2kg/m2
    Thickness40mm
    Density45±2kg/m3
    Panel WidthStandard:500mm, 535mm, 550mm, 600mm
    Surface TreatmentFinished


    Panel Design



    Classic Cassette


    Universal Line



    Two Rib Liine



    Top One Line




    Middle Rib Line



    Micro Wave Line



    Flat



    Long Pane



    Color Customized


    Choose the perfect color for your garage door.

    With 36 years of experience in custom garage doors,

    Xufeng Door offers a wide variety of colors to suit your style.


    Panel Structure


    Finger Protectional Type Panel


    Standard Width: 480mm, 500mm, 530mm, 550mm,


    Max.length: 11.8m


    Thickness: 40+2mm


    Density: 45+2kg/m3


    Material: Galvanised Steel


    Epoxy paint


    Foaming: PU foam DOW






    Garage Door Accessories List


    • Top Bracket/Bottom Bracket/Cable Brack Device(optional)

    • Middle Hinge/Adjustable Hinge

    • Roler(steel/nylon,short/long stem)

    • Spring Broken Device/Bearing Bracket(optional)

    • Cable Drum/Steel Cable/Shaft Coupler

    • Torsion Spring

    • Tubular Shaft/K-Shaft(optional)

    • Vertical Track & HoriztonalTrack

    • L-Frame

    • Assist Angle/Angle lron

    • Handle/Emergency Lock

    • Motor

    • Fasteners


    Installation Options


    Extension Spring


    Headroom min.150mm(6")

    Economic

    For little installation space

    for the garage door.



    Torsion Spring- Single track

    Headroom min.350mm(14")

    without L-framemin.

    450mm(18") with L-frame


    Torsion Spring- Doubletrack

    Headroom: general required 250mm(10")

    Can adjust if headroom only 200mm(8")


    Rear Spring


    Headroom min.150mm(6")

    Upgrade, Protect and Extend

    Window Options


    Windows available on Standard, Flush and Vertical Short panels.


    garage door with small vision window
    XFW-1 Plain short                                          XFW-2 Diamond                                               XFW-3 Cross
    garage doors with vision window
    XFW-4 Charleston                                           XFW-5 Mountain                                              XFW-6 Sunset
    garage door small vision window
    XFW-7 Sunset(4/6/8/10 panels across)                                               XFW-8 Sunset(4/8 panels across)             vision window garage doors
    XFW-9 Sunset(6 panels across)
    Standard panel garage door
    XFWL-1 Stockton
    Long panel garage doors
      XFWL-2 Cascade                                                                       XFWL-3 Waterton
    Long panel sectional doors

    XFWL-4 Wagon wheel

    FAQ


    Q1:What is your MOQ?

    A:Our automatic continous line required 200m.Also accept sample order


    Q2:What is the delivery time?

    A:About 15-30days, need check stocked raw material spec is enough or not.


    Q3:What is the Max. available size of the panels?

    A:The max. length of panel can be 11.8m. The panel range from 430mm ~ 610mm, but we need check stocked raw material.

    Our standard size for European type panel is 500mm, 530mm, 550mm, 600mm etc.

    Standard size for American type panel is 460mm,488mm, 535mm


    Q4:What about your package?

    A:Carton box for full container order, Polywood box for sample order


    Q5:What kind of payment terms would you accept?

    A:Usually we accept T/T, L/C, Western Union, Credit Card etc. If you prefer other payment terms, please feel free to discuss with us.


    Q6:We want to be your agent of our area. How to apply for this?

    A:Please send your idea and your profile to us. Let's cooperate.


    Q7:Can I get a sample to check your quality?

    A:Sample panel is available.


    Q8:How can I know the price exactly?

    A:Please give the exactly size and quantity of your required door. We can give you a detail quotation based on your requirements.


    Q9:Is it difficult to install your door?

    A:Easy to install. We have manual book and installation video for your reference.

    We also provide support for training your staff in our factory or let our engineer go to your city provide techinical support.


    Q10:Do you produce other products? What about your export experience?

    A:Except for sectional garage door, we also produce industrial door, roll shutter door, high speed door, hangar door etc.

    We had export since 2003 year, we have cooperated with Low'es, RONA etc. Had designed and produced for Maldives airport.

    Mongolia airport, Nepal airport, Romania airport etc.
