PRODUCT DETAILS

SECTIONAL INDUSTRIAL DOOR
Industrial Finger Protection Panel
With 1.0mm thickness reinforcement steel
Sponge seal
Standard Width: 500mm
Max. length: 11.8m
Thickness: 40+2mm
Density: 45±2kg/m3
Material: Galvanised steel Epoxy paint
  • Sectional Industrial Door

    Sectional industrial doors are crafted with double-layered color steel panels, featuring high-density polyurethane foam insulation for superior thermal efficiency.

    The sectional industrial door panels are designed with finger protection, offering enhanced safety and long-lasting durability.

    Xufeng Door provides a diverse selection of sectional industrial doors, tailored to meet your unique requirements. We offer all the design elements and features necessary to bring your vision to life.


    Why Choose XUFENG European Type Garage Door?

    Rich Manufacturing Experience

    With over 36 years of expertise, Xufeng Door offers advanced equipment and a trusted professional team.

    Efficient Insulation

    Double-layer steel panels with polyurethane foam reduce energy loss,

    perfect for temperature-sensitive environments like food processing and logistics.

    Fast and Efficient Operation

    High-speed motors enable quick opening and closing, improving workflow in busy industrial settings.

    Enhanced Safety

    Equipped with features like finger protection, anti-fall devices,

    spring break protection, safety airbags, and obstruction-reversal systems to minimize accidents.

    Convenient Control Options

    Supports multiple control methods, including mobile apps, remote controls,

    pull cords, sensors, and radar systems, for versatile use.

    Low Maintenance, Long Lifespan

    Durable design with simple maintenance reduces repair needs and costs.

    Customizable Design

    Available in various sizes, colors, and styles to suit different industries and preferences.





    Product Details

    Product TypeInsulation Industrial Door
    ApplicationIndustrial Ware House, Logistic Warehouse
    Open StyleStandard Overhead Lift, High Lift, Vertical Lift
    Including2" Galvanised Hardware, 3" Galvanised Hardware, Torsion Spring
    Safety Optional

    Spring Broken Device, Cable Broken Device,

    Photocell, Radar, Geomagnetic, Pull Rope, Wall Switch

    MaterialGlavanised Steel, PU Foam ( DOW) CFC Free,Pe Protective Film
    Steel Thickness0.326mm, 0.45mm thickness
    Panel Color

    Standard: RAL9002 Offwhite. Other Colors can be Customed

    Panel DesignFinger Protection, Non Finger Protection
    Panel Weight9.2kg/m2-11.2kg/m2
    Thickness40mm,50mm,60mm,80mm
    Density45±2kg/m3
    Panel WidthStandard:500mm
    Surface TreatmentFinished


    Industrial Door Panel



    Panel Design: 4 line design, Micro wave line design


    Panel Colors: Standard color is RAL9002 Offwhite. Other Colors can be Customed


    Surface Embossment: Wood grain, Orange peel




    Product Structure




    Industrial Finger Protectional Type Panel


    With 1.0mm thickness reinforcement steel


    Spongo seal


    Standard Width: 500mm


    Max.length: 11.8m


    Thickness: 40+2mm


    Density: 45+2kg/m3


    Material: Galvanised Steel


    Epoxy paint


    Foaming: PU foam DOW





    Industrial Door Structure

    Sectional industrial door consists of door panels, tracks,

    a balance system, a drive and control system, safety

    features, and other optional accessories.

    It is designed for durability, safety, and versatility.




    Industrial Motor

    AC220V1380V

    With emergency chain system



    Air Bag System



    Spring Broken Device



    Cable Broken Device




    Cable Drum



    Reinforced Industrial Bracket



    Control Box



    Reinforced Industrial Hinge



    Opening Type



    Vertical Lifting



    High Lifting



    Standard Lifting



    Optional Plan



    Door



    Door with wicket door



    Door with vision window



    Door with wicket doorwindow



    Control Methed



    Manual Control



    Comtrol Box



    Remote Control



    App Control




    Pull Rope Control



    Photocell Control



    Magnetie Loop Control



    Radar Control


    RFQ


    Q1:What is your MOQ?

    Re:Our automatic continous line required 200m.Also accept sample order.


    Q2:What is the delivery time?

    Re:About 15-30days, need check stocked raw material spec is enough or not.


    Q3:What is the Max. available size of the panels?

    Re:The max. length of panel can be 11.8m. Standard width 500mm.


    Q4:What about your package?

    Re:Carton box for full container order, Polywood box for sample order.


    Q5:What kind of payment terms would you accept?

    Re:Usually we accept T/T, L/C, Western Union, Credit Card etc. If you prefer other payment terms, please feel free to discuss with us.


    Q6:We want to be your agent of our area. How to apply for this?

    Re:Please send your idea and your profile to us. Let's cooperate.


    Q7:Can I get a sample to check your quality?

    Re:Sample panel is available.


    Q8:How can I know the price exactly?

    Re:Please give the exactly size and quantity of your required door. We can give you a detail quotation based on your requirements.


    Q9:Is it difficult to install your door?

    Re:Easy to install. We have manual book and installation video for your reference.We also provide support for training your staff in our factory or let our engineer go to your city provide techinical support.


    Q10:Do you produce other products? What about your export experience?

    Re. Except for sectional garage door, we also produce industrial door, roll shutter door, high speed door, hangar door etc.We had export since 2003 year, we have cooperated with Low'es, RONA etc.Had designed and produced for Maldives airport. Mongolia airport, Nepal airport, Romania airport etc.
