PRODUCT DETAILS

AMERICAN TYPE GARAGE DOOR
Non-Finger Protectional Panel
Standard Width: 460mm(for 7'6" height),488mm(for 8' height), 530mm(for 7' height)
Max. length: 11.8m
Thickness: 40+2mm (1 3/5")
Density: 45±2kg/m3
Material: Galvanised steel Epoxy paint
Foaming: PU foam

  • American Type Garage Door

    American type garage doors are made with double-layered color steel panels, filled with high-density polyurethane foam for insulation.

    The American style garage door panels are designed with non finger protection, with an attractive appearance and low maintenance. They offer great durability, insulation, and reliability.

    Xufeng Door offers a diverse selection of American-style garage doors, ranging from timeless traditional designs to sturdy classic steel options and sleek modern styles. We provide all the design elements and features necessary to bring your vision to life.



    Why Choose XUFENG American Type Garage Door?


    Over 36 Years of Manufacturing Excellence

    Xufeng Door has been a professional manufacturer of garage doors and industrial doors since 1988.

    Comprehensive Customization Options
    We offer full customization to meet your specific needs, including garage door panel size, color, design, thickness, width, safety features, materials, and more.

    Eco-Friendly Insulation
    Our garage doors are made with fluoride-free, eco-friendly polyurethane foam, ensuring excellent insulation performance while being environmentally conscious.

    Superior Insulation for Energy Efficiency
    American-style garage doors are designed to minimize heat transfer and energy loss, making them an ideal choice for energy-conscious homeowners.

    Unmatched Durability and Strength
    Crafted from high-quality steel, our garage doors are built to withstand wind, rain, and impact, ensuring long-lasting performance and reliability.

    Low Maintenance for Hassle-Free Living
    American-style garage doors require minimal upkeep, with easy cleaning and maintenance that saves you time and effort.







    Product Details

    Product TypePU Foam Insulated Garage Door
    ApplicationResidential House, Villa
    Open StyleOverhead Lift
    IncludingAll track and installation hardware, Installation Instructions
    Safety OptionalSpring Broken Device, Cable Broken Device, Photocell, Warning Light
    Material

    2 Sheets of Galvanized Steel, PU Foam (DOW) CFC Free,

     EPDM Rubber Seal, PE Protective Film

    Steel Thickness0.326mm, 0.45mm thickness
    Panel Color

    Standard: RAL9016 White, Optional: RAL7016 Grey, RAL9017 Black, RAL8017 Brown,

     RAL9006 Silver, Wooden Color etc. Other Colors can be Customed

    Panel DesignNon Finger Protection
    Panel Weight8.3kg/m2-10.2kg/m2
    ThicknessRegular: 1 3/5 inch; Optional: 2 inches with better insulation
    Density45±2kg/m3
    Panel WidthStandard: 460mm (for 7'6" height),488mm(for 8' height), 530mm(for 7' height)
    Surface TreatmentFinished


    Panel Design



    Classic Cassette



    Universal Line



    Two Rib Liine



    Top One Line



    Middle Rib Line



    Micro Wave Line



    Flat



    Long Pane





    Color Customized


    Choose the perfect color for your garage door.

    With 36 years of experience in custom garage doors,

    Xufeng Door offers a wide variety of colors to suit your style.



    Panel Structure


    Non Finger Protectional Type Panel


    Standard Width: 460mm (for 7'6" height), 488mm(for 8' height), 530mm(for 7' height)


    Max.length: 11.8m


    Thickness: Regular: 1 3/5 inch; Optional: 2 inches with better insulation


    Density: 45+2kg/m3


    Material: Galvanised Steel


    Epoxy paint


    Foaming: PU foam DOW







    Garage Door Accessories List


    • Top Bracket/Bottom Bracket/Cable Brack Device(optional)

    • Hinge: 0#, 1#, 2#, 3#, 4#

    • Roler(steel/nylon,short/long stem)

    • Spring Broken Device/Bearing Bracket(optional)

    • Cable Drum/Steel Cable/Shaft Coupler

    • Torsion Spring

    • Tubular Shaft/K-Shaft(optional)

    • Vertical Track & HoriztonalTrack

    • Flag Bracket & Side Bracket

    • Assist Angle/Angle lron

    • Handle/Emergency Lock

    • Motor

    • Fasteners



    Installation Options


    Extension Spring


    Headroom min.150mm(6")

    Economic

    For little installation space

    for the garage door.




    Torsion Spring- Single track

    Headroom min.350mm(14")

    without L-framemin.

    450mm(18") with L-frame



    Torsion Spring- Doubletrack

    Headroom: general required 250mm(10")

    Can adjust if headroom only 200mm(8")



    Rear Spring


    Headroom min.150mm(6")

    Upgrade, Protect and Extend





    Window Options


    Windows available on Standard, Flush and Vertical Short panels.


    garage door with small vision window
    XFW-1 Plain short                                          XFW-2 Diamond                                               XFW-3 Cross
    garage doors with vision window
    XFW-4 Charleston                                           XFW-5 Mountain                                              XFW-6 Sunset
    garage door small vision window
    XFW-7 Sunset(4/6/8/10 panels across)                                               XFW-8 Sunset(4/8 panels across)             vision window garage doors
    XFW-9 Sunset(6 panels across)
    Standard panel garage door
    XFWL-1 Stockton
    Long panel garage doors
      XFWL-2 Cascade                                                                       XFWL-3 Waterton
    Long panel sectional doors

    XFWL-4 Wagon wheel

    FAQ


    Q1:What is your MOQ?

    A:Our automatic continous line required 200m (61 feet).Also accept sample order


    Q2:What is the delivery time?

    A:About 15-35days, need check stocked raw material spec is enough or not.


    Q3:What is the Max. available size of American type panels?

    A:Standard size for American type panel is for door height 7', 7'6", 8', door width from 8' to 20'


    Q4:What about your package?

    A:Carton box for full container order, Polywood box for sample order


    Q5:What kind of payment terms would you accept?

    A:Usually we accept T/T, L/C, Western Union, Credit Card etc. If you prefer other payment terms, please feel free to discuss with us.


    Q6:We want to be your agent of our area. How to apply for this?

    A:Please send your idea and your profile to us. Let's cooperate.


    Q7:Can I get a sample to check your quality?

    A:Sample panel is available.


    Q8:How can I know the price exactly?

    A:Please give the exactly size and quantity of your required door. We can give you a detail quotation based on your requirements.


    Q9:Is it difficult to install your door?

    A:Easy to install. We have manual book and installation video for your reference.We also provide support for training your staff in our factory or let our engineer go to your city provide techinical support.


    Q10:Do you produce other products? What about your export experience?

    A:Except for sectional garage door, we also produce industrial door, roll shutter door, high speed door, hangar door etc.We had export since 2003 year, we have cooperated with Low'es, RONA etc.Had designed and produced for Maldives airport. Mongolia airport, Nepal airport, Romania airport etc.
